Admittance Analysis of the Spark Circuit

Introduction

The spark circuit topology (R || C_mut in series with C_sh) requires careful analysis. While we could work entirely with impedances, using admittance simplifies the parallel combination and provides clearer insight into circuit behavior.

Why Use Admittance?

For the spark circuit topology (parallel R||C_mut, in series with C_sh), admittance simplifies calculations.

Parallel elements: Add admittances directly

Y_total = Y₁ + Y₂ + Y₃ + ...
vs impedances: 1/Z_total = 1/Z₁ + 1/Z₂ + ... (messy!)

Our circuit:

Y_mut_R = Y_Cmut + Y_R  (parallel: C_mut || R)
Then series with C_sh requires impedance: Z = Z_mut_R + Z_Csh
Then convert back: Y_total = 1/Z_total

Admittance makes the first step (parallel combination) trivial, and we only need to handle the series combination once.

Deriving the Total Admittance Formula

Let's work through the complete derivation step by step.

Step 1: Admittance of R and C_mut in parallel

Y_R = G = 1/R
Y_Cmut = jωC_mut = jB₁  (where B₁ = ωC_mut)

Y_mut_R = G + jB₁

Step 2: Convert to impedance for series combination

Z_mut_R = 1/(G + jB₁)

Step 3: Add impedance of C_sh in series

Z_Csh = 1/(jωC_sh) = -j/(ωC_sh) = 1/(jB₂)  (where B₂ = ωC_sh)

Z_total = Z_mut_R + Z_Csh
Z_total = 1/(G + jB₁) + 1/(jB₂)

Step 4: Find common denominator

Z_total = [jB₂ + (G + jB₁)] / [(G + jB₁) × jB₂]
Z_total = [G + j(B₁ + B₂)] / [jB₂(G + jB₁)]

Step 5: Invert to get admittance

Y_total = 1/Z_total = [jB₂(G + jB₁)] / [G + j(B₁ + B₂)]

Y_total = [(G + jB₁) × jB₂] / [G + j(B₁ + B₂)]

This is the fundamental admittance equation for the spark circuit.

Extracting Real and Imaginary Parts

To use this formula, we need to separate it into Re{Y} and Im{Y}.

Multiply numerator:

(G + jB₁) × jB₂ = jGB₂ + j²B₁B₂ = jGB₂ - B₁B₂
                = -B₁B₂ + jGB₂

So:

Y = [-B₁B₂ + jGB₂] / [G + j(B₁ + B₂)]

To separate real and imaginary parts, multiply numerator and denominator by complex conjugate of denominator:

Denominator conjugate: G - j(B₁ + B₂)
Denominator magnitude squared: G² + (B₁ + B₂)²

After algebra (multiply out and simplify):

Re{Y} = GB₂² / [G² + (B₁ + B₂)²]

Im{Y} = B₂[G² + B₁(B₁ + B₂)] / [G² + (B₁ + B₂)²]

These are the working formulas for calculating admittance from R, C_mut, C_sh.

Formula Summary

Given R, C_mut, C_sh, and frequency f:

Step 1: Calculate component values

ω = 2πf
G = 1/R
B₁ = ωC_mut
B₂ = ωC_sh

Step 2: Calculate admittance

Re{Y} = GB₂² / [G² + (B₁ + B₂)²]

Im{Y} = B₂[G² + B₁(B₁ + B₂)] / [G² + (B₁ + B₂)²]

Y = Re{Y} + j×Im{Y}

Step 3: Magnitude and phase

|Y| = √[Re{Y}² + Im{Y}²]
φ_Y = atan(Im{Y}/Re{Y})

Converting to Impedance

From Y = G_total + jB_total:

Z = 1/Y = 1/(G_total + jB_total)

Multiply by conjugate:
Z = (G_total - jB_total) / (G_total² + B_total²)

R_total = G_total / (G_total² + B_total²)
X_total = -B_total / (G_total² + B_total²)

Or directly:
|Z| = 1/|Y|
φ_Z = -φ_Y  (opposite sign!)

Worked Example: Complete Y and Z Calculation

Given:

Frequency: f = 200 kHz → ω = 2π × 200×10³ = 1.257×10⁶ rad/s
C_mut = 8 pF = 8×10⁻¹² F
C_sh = 6 pF = 6×10⁻¹² F
R = 100 kΩ = 10⁵ Ω

Find: Y_total (rectangular), Z_total (rectangular and polar)

Solution:

Step 1: Calculate component values

G = 1/R = 1/(10⁵) = 10⁻⁵ S = 10 μS
B₁ = ωC_mut = 1.257×10⁶ × 8×10⁻¹² = 10.06×10⁻⁶ S = 10.06 μS
B₂ = ωC_sh = 1.257×10⁶ × 6×10⁻¹² = 7.54×10⁻⁶ S = 7.54 μS

Step 2: Calculate Re{Y}

Re{Y} = GB₂² / [G² + (B₁ + B₂)²]

Numerator: 10 × (7.54)² = 10 × 56.85 = 568.5 μS²
Denominator: (10)² + (10.06 + 7.54)² = 100 + (17.6)² = 100 + 309.8 = 409.8 μS²

Re{Y} = 568.5 / 409.8 = 1.387 μS

Step 3: Calculate Im{Y}

Im{Y} = B₂[G² + B₁(B₁ + B₂)] / [G² + (B₁ + B₂)²]

Numerator inner: G² + B₁(B₁ + B₂) = 100 + 10.06×17.6 = 100 + 177.1 = 277.1 μS²
Numerator: 7.54 × 277.1 = 2089.3 μS³
Denominator: 409.8 μS² (same as before)

Im{Y} = 2089.3 / 409.8 = 5.10 μS

Step 4: Admittance result

Y_total = 1.387 + j5.10 μS
|Y| = √(1.387² + 5.10²) = √(1.92 + 26.01) = √27.93 = 5.28 μS
φ_Y = atan(5.10/1.387) = atan(3.68) = 74.8°

Step 5: Convert to impedance

|Z| = 1/|Y| = 1/(5.28×10⁻⁶) = 189 kΩ
φ_Z = -φ_Y = -74.8°

In rectangular:
R_total = |Z| × cos(φ_Z) = 189 × cos(-74.8°) = 189 × 0.263 = 49.7 kΩ
X_total = |Z| × sin(φ_Z) = 189 × sin(-74.8°) = 189 × (-0.965) = -182 kΩ

Z_total = 49.7 - j182 kΩ = 189 kΩ ∠-74.8°

Interpretation:

Impedance is strongly capacitive (φ_Z = -74.8°)
Equivalent resistance ≈ 50 kΩ (half of actual R due to capacitive divider)
Large capacitive reactance dominates

Visualization notes:

LEFT: Admittance plane (Y = G + jB)
- Point at (1.387, 5.10) μS
- Angle φ_Y = 74.8° from horizontal
- Positive B means capacitive in admittance
RIGHT: Impedance plane (Z = R + jX)
- Point at (49.7, -182) kΩ
- Angle φ_Z = -74.8° below horizontal
- Negative X means capacitive in impedance
Connection: Angles are opposite (φ_Z = -φ_Y), magnitudes invert (|Z| = 1/|Y|)

Key Takeaways

Admittance simplifies parallel combinations: Y_parallel = Y₁ + Y₂ + ...
Fundamental formula: Y = [(G + jB₁) × jB₂] / [G + j(B₁ + B₂)]
Working formulas:
- Re{Y} = GB₂² / [G² + (B₁ + B₂)²]
- Im{Y} = B₂[G² + B₁(B₁ + B₂)] / [G² + (B₁ + B₂)²]
Conversion: |Z| = 1/|Y| and φ_Z = -φ_Y
Typical spark: strongly capacitive with large |Im{Y}| compared to Re{Y}

Practice

{exercise:fund-ex-03}

Problem 1: For f = 150 kHz, C_mut = 10 pF, C_sh = 8 pF, R = 80 kΩ, calculate Y_total (real and imaginary parts).

Problem 2: An admittance Y = 2.0 + j4.5 μS. Convert to impedance Z in both rectangular and polar forms.

Problem 3: Show algebraically that if R → ∞ (open circuit), the formula reduces to Y = jωC_mut × C_sh/(C_mut + C_sh), which is two capacitors in series.
